House Plan 5472, White Haven Place
Floor plans
MEN 5472
House Plan 5472, White Haven Place
Plan Details
- Plan Number: MEN 5472
- Total Living Space:2411Sq.Ft.
- Bedrooms: 3
- Full Baths: 3
- Half Baths: N/A
- Garage: 3 Bay
- Garage Type: N/A
- Carport: N/A
- Carport Type: N/A
- Stories: 1
- Width Ft.: 92
- Width In.: N/A
- Depth Ft.: 71
- Depth In.: 2
Description
Specifications
- Total Living Space:2411Sq.Ft.
- Main Floor: 2411 Sq.Ft
- Upper Floor (Sq.Ft.): N/A
- Lower Floor (Sq.Ft.): N/A
- Bonus Room (Sq.Ft.): 318 Sq.Ft.
- Porch (Sq.Ft.): 814 Sq.Ft.
- Garage (Sq.Ft.): 796 Sq.Ft.
- Total Square Feet: 4339 Sq.Ft.
- Customizable: Yes
- Wall Construction: 2x6
- Vaulted Ceiling Height: Yes
- Main Ceiling Height: 9
- Upper Ceiling Height: N/A
- Lower Ceiling Height: N/A
- Roof Type: Metal
- Main Roof Pitch: 7:12
- Porch Roof Pitch: 12:12
- Roof Framing Description: Stick
- Designed Roof Load: 45lbs
- Ridge Height (Ft.): 22
- Ridge Height (In.): 2
- Insulation Exterior: R19
- Insulation Floor Minimum: R19
- Insulation Ceiling Minimum: R30
- Lower Bonus Space (Sq.Ft.): N/A
