House Plan 756 Geary Lane, Affordable House Plan

>

Floor plans

NDG 756

House Plan 756 Geary Lane, Affordable House Plan

PDF: $800.00

Plan Details

  • Plan Number: NDG 756
  • Total Living Space:1552Sq.Ft.
  • Bedrooms: 4
  • Full Baths: 2
  • Half Baths: N/A
  • Garage: 2 Bay Yes
  • Garage Type: Front Load
  • Carport: N/A
  • Carport Type: N/A
  • Stories: 1
  • Width Ft.: 49
  • Width In.: 10
  • Depth Ft.: 64
  • Depth In.: 4

Description

This narrow lot design by Nelson Design Group provides all the conveniences a family needs. The split design offers much privacy while maintaining the closeness for the children’s needs. The step saver kitchen with snack bar opens to the breakfast room. Family will gather in the open great room with fireplace and access to the rear grilling porch for healthy cuisine dining. Ample storage throughout this home completes the design.

Specifications

  • Total Living Space:1552Sq.Ft.
  • Main Floor: 1552 Sq.Ft
  • Upper Floor (Sq.Ft.): N/A
  • Lower Floor (Sq.Ft.): N/A
  • Bonus Room (Sq.Ft.): N/A
  • Porch (Sq.Ft.): 151 Sq.Ft.
  • Garage (Sq.Ft.): 461 Sq.Ft.
  • Total Square Feet: 2164 Sq.Ft.
  • Customizable: Yes
  • Wall Construction: 2x4
  • Vaulted Ceiling Height: No
  • Main Ceiling Height: 9
  • Upper Ceiling Height: N/A
  • Lower Ceiling Height: N/A
  • Roof Type: Shingle
  • Main Roof Pitch: 7:12
  • Porch Roof Pitch: N/A
  • Roof Framing Description: Stick
  • Designed Roof Load: 45lbs
  • Ridge Height (Ft.): 17
  • Ridge Height (In.): 9
  • Insulation Exterior: R13
  • Insulation Floor Minimum: R19
  • Insulation Ceiling Minimum: R30
  • Lower Bonus Space (Sq.Ft.): N/A
