House Plan 220 Chestnut Lane, French Traditional House Plan
Plan Details
- Plan Number: NDG 220
- Total Living Space:1764Sq.Ft.
- Bedrooms: 3
- Full Baths: 2
- Half Baths: N/A
- Garage: 2 Bay Yes
- Garage Type: Front Load
- Carport: No
- Carport Type: N/A
- Stories: 1
- Width Ft.: 53
- Width In.: N/A
- Depth Ft.: 55
- Depth In.: 4
Description
We have created an ideal split bedroom home with privacy for everyone. An inviting great room will certainly draw the entire family together as you enjoy the fireplace’s glow. Your functional kitchen allows you to entertain easily at large parties in the dining room or family night dinners in the cozy breakfast room. The rear covered porch provides the ideal place for grilling steaks. The children and yourself will find the secluded bedrooms perfect as the long day ends.
Specifications
- Total Living Space:1764Sq.Ft.
- Main Floor: 1764 Sq.Ft
- Upper Floor (Sq.Ft.): N/A
- Lower Floor (Sq.Ft.): N/A
- Bonus Room (Sq.Ft.): N/A
- Porch (Sq.Ft.): 130 Sq.Ft.
- Garage (Sq.Ft.): 488 Sq.Ft.
- Total Square Feet: 2382 Sq.Ft.
- Customizable: Yes
- Wall Construction: 2x4
- Vaulted Ceiling Height: No
- Main Ceiling Height: 8
- Upper Ceiling Height: N/A
- Lower Ceiling Height: N/A
- Roof Type: Shingle
- Main Roof Pitch: 8:12
- Porch Roof Pitch: N/A
- Roof Framing Description: Stick
- Designed Roof Load: 45lbs
- Ridge Height (Ft.): 22
- Ridge Height (In.): 0
- Insulation Exterior: R13
- Insulation Floor Minimum: R19
- Insulation Ceiling Minimum: R30
- Lower Bonus Space (Sq.Ft.): N/A
