House Plan 5308 Englewood Place, Riverbend House Plan

Floor plans

MEN 5308

House Plan 5308 Englewood Place, Riverbend House Plan

PDF: $1,350.00

Plan Details

  • Plan Number: MEN 5308
  • Total Living Space:2068Sq.Ft.
  • Bedrooms: 2
  • Full Baths: 3
  • Half Baths: 1
  • Garage: 2 Bay
  • Garage Type: Front Load
  • Carport: No
  • Carport Type: N/A
  • Stories: 1.5
  • Width Ft.: 89
  • Width In.: 8
  • Depth Ft.: 51
  • Depth In.: N/A

Description

Specifications

  • Total Living Space:2068Sq.Ft.
  • Main Floor: 1685 Sq.Ft
  • Upper Floor (Sq.Ft.): 383 Sq.Ft.
  • Lower Floor (Sq.Ft.): N/A
  • Bonus Room (Sq.Ft.): 677 Sq.Ft.
  • Porch (Sq.Ft.): 807 Sq.Ft.
  • Garage (Sq.Ft.): 824 Sq.Ft.
  • Total Square Feet: 4376 Sq.Ft.
  • Customizable: Yes
  • Wall Construction: 2x4
  • Vaulted Ceiling Height: No
  • Main Ceiling Height: 9
  • Upper Ceiling Height: 8
  • Lower Ceiling Height: N/A
  • Roof Type: Metal
  • Main Roof Pitch: 9:12
  • Porch Roof Pitch: 4:12
  • Roof Framing Description: stick
  • Designed Roof Load: 45lbs
  • Ridge Height (Ft.): 24
  • Ridge Height (In.): 8
  • Insulation Exterior: R13
  • Insulation Floor Minimum: R19
  • Insulation Ceiling Minimum: R30
  • Lower Bonus Space (Sq.Ft.): N/A
