House Plan 195 Richmond Drive, French Traditional House Plan

>

Floor plans

NDG 195

House Plan 195 Richmond Drive, French Traditional House Plan

PDF: $1,000.00

Plan Details

  • Plan Number: NDG 195
  • Total Living Space:2238Sq.Ft.
  • Bedrooms: 4
  • Full Baths: 2
  • Half Baths: N/A
  • Garage: 2 Bay Yes
  • Garage Type: Front Load
  • Carport: No
  • Carport Type: N/A
  • Stories: 1
  • Width Ft.: 60
  • Width In.: 6
  • Depth Ft.: 69
  • Depth In.: 2

Description

Whoever said it’s the little details that count the most must have lived in this amazing home. The brick facade with multiple-gabled, hip roof line and stunning half-round transforms is sure to capture attention. Friends and family alike will marvel at the free-flowing living areas punctuated with a corner pass-through fireplace. The hearth room provides an alternate gathering place when the kids take over the great room. The user-friendly kitchen offers plenty of room to maneuver and an eat-at bar for quickie meals. The master suite’s immense walk-in closet can handle even the most dedicated pack rat and then some.

Specifications

  • Total Living Space:2238Sq.Ft.
  • Main Floor: 2238 Sq.Ft
  • Upper Floor (Sq.Ft.): N/A
  • Lower Floor (Sq.Ft.): N/A
  • Bonus Room (Sq.Ft.): N/A
  • Porch (Sq.Ft.): 238 Sq.Ft.
  • Garage (Sq.Ft.): 517 Sq.Ft.
  • Total Square Feet: 2993 Sq.Ft.
  • Customizable: Yes
  • Wall Construction: 2x4
  • Vaulted Ceiling Height: No
  • Main Ceiling Height: 9
  • Upper Ceiling Height: N/A
  • Lower Ceiling Height: N/A
  • Roof Type: Shingle
  • Main Roof Pitch: 8:12
  • Porch Roof Pitch: 8:12
  • Roof Framing Description: Stick
  • Designed Roof Load: 45lbs
  • Ridge Height (Ft.): 21
  • Ridge Height (In.): 2
  • Insulation Exterior: R13
  • Insulation Floor Minimum: R19
  • Insulation Ceiling Minimum: R30
  • Lower Bonus Space (Sq.Ft.): N/A
