House Plan 987C Belmont Avenue, Stone-And-Brick House Plan
Floor plans
NDG 987C
House Plan 987C Belmont Avenue, Stone-And-Brick House Plan
PDF: $800.00
Plan Details
- Plan Number: NDG 987C
- Total Living Space:1923Sq.Ft.
- Bedrooms: 3
- Full Baths: 2
- Half Baths: N/A
- Garage: 2 Bay Yes
- Garage Type: Rear Load
- Carport: N/A
- Carport Type: N/A
- Stories: 1
- Width Ft.: 35
- Width In.: N/A
- Depth Ft.: 80
- Depth In.: 6
Description
This unique design by Nelson Design Group offers three exterior selections for you and your home builder to choose from. Brick, stone and a combination of both allow you to achieve the street appeal that will best suit your neighborhood. The covered entry leads into the foyer with French doors to the study or den. The open great room features a boxed ceiling treatment as well as a gas fireplace. The step saver kitchen has a convenient walk-in pantry with a snack bar open to the dining area. The courtyard is accessed from the great room and can feature an herb garden. The master suite is tucked to the rear of the design for privacy.
Specifications
- Total Living Space:1923Sq.Ft.
- Main Floor: 1923 Sq.Ft
- Upper Floor (Sq.Ft.): N/A
- Lower Floor (Sq.Ft.): N/A
- Bonus Room (Sq.Ft.): N/A
- Porch (Sq.Ft.): 156 Sq.Ft.
- Garage (Sq.Ft.): 532 Sq.Ft.
- Total Square Feet: 2611 Sq.Ft.
- Customizable: Yes
- Wall Construction: 2x4
- Vaulted Ceiling Height: No
- Main Ceiling Height: 9
- Upper Ceiling Height: N/A
- Lower Ceiling Height: N/A
- Roof Type: Shingle
- Main Roof Pitch: 10:12
- Porch Roof Pitch: N/A
- Roof Framing Description: Stick
- Designed Roof Load: 45lbs
- Ridge Height (Ft.): 22
- Ridge Height (In.): 8
- Insulation Exterior: R13
- Insulation Floor Minimum: R19
- Insulation Ceiling Minimum: R30
- Lower Bonus Space (Sq.Ft.): N/A
