House Plan 5070 The Wingate, French Classic House Plan

House Plan MEN 5070 Main Floor
House Plan MEN 5070 Main Floor

Floor plans

MEN 5070

House Plan 5070 The Wingate, French Classic House Plan

PDF: $1,650.00

Plan Details

  • Plan Number: MEN 5070
  • Total Living Space:2494Sq.Ft.
  • Bedrooms: 3
  • Full Baths: 2
  • Half Baths: 1
  • Garage: 3 Bay Yes
  • Garage Type: Side Load
  • Carport: N/A
  • Carport Type: N/A
  • Stories: 1
  • Width Ft.: 67
  • Width In.: N/A
  • Depth Ft.: 68
  • Depth In.: N/A


Step inside this stunning home and you'll find yourself in the great open plan, perfect for entertaining. After all our guests have left you can relax in the private master suite or in the beautiful free standing tub in the master bath. The home study with the elegant barn door entry is the perfect place to work from home or have an extra space for company to stay in your home.


  • Total Living Space:2494Sq.Ft.
  • Main Floor: 2494 Sq.Ft
  • Upper Floor (Sq.Ft.): N/A
  • Lower Floor (Sq.Ft.): N/A
  • Bonus Room (Sq.Ft.): N/A
  • Porch (Sq.Ft.): 199 Sq.Ft.
  • Garage (Sq.Ft.): 483 Sq.Ft.
  • Total Square Feet: 3176 Sq.Ft.
  • Customizable: Yes
  • Wall Construction: 2x4
  • Vaulted Ceiling Height: No
  • Main Ceiling Height: 9
  • Upper Ceiling Height: N/A
  • Lower Ceiling Height: N/A
  • Roof Type: Shingle
  • Main Roof Pitch: 12:12
  • Porch Roof Pitch: N/A
  • Roof Framing Description: Stick
  • Designed Roof Load: 45lbs
  • Ridge Height (Ft.): 30
  • Ridge Height (In.): 8
  • Insulation Exterior: R13
  • Insulation Floor Minimum: R19
  • Insulation Ceiling Minimum: R30
  • Lower Bonus Space (Sq.Ft.): N/A
