House Plan 491 Brookshire, Multi-Family House Plan

House Plan NDG 491 Main Floor
House Plan NDG 491 Main Floor

Floor plans

NDG 491

House Plan 491 Brookshire, Multi-Family House Plan

PDF: $1,200.00

Plan Details

  • Plan Number: NDG 491
  • Total Living Space:1169Sq.Ft.
  • Bedrooms: 3
  • Full Baths: 2
  • Half Baths: N/A
  • Garage: No
  • Garage Type: N/A
  • Carport: N/A
  • Carport Type: N/A
  • Stories: 1
  • Width Ft.: 37
  • Width In.: N/A
  • Depth Ft.: 72
  • Depth In.: 7

Description

This lovely duplex plan includes columns on the front entry porch and a pleasing interior. Round columns and a hip roof enhance this three-bedroom plan complete with a large kitchen/breakfast area and a convenient hall laundry closet. A spacious great room includes a small sitting area by the front window for afternoon reading. And for the handyman, the rear patio has a storage room and allows privacy from the adjoining neighbor.

Floor Plan Specifications:
Heat/Cooled Unit #1: 1169 SQ.FT
Heat/Cooled Unit #2: 1169 SQ.FT
Heat/Cooled Both Duplex Units: 2338 SQ. FT
Storage Unit 1: 26 SQ. FT
Storage Unit 2: 26 SQ. FT
Storage Both Units: 52 SQ. FT
Porch Unit 1: 26 SQ. FT
Porch Unit 2: 26 SQ. FT
Porch Both Units: 52 SQ. FT

Total: 2442 SQ. FT

Specifications

  • Total Living Space:1169Sq.Ft.
  • Main Floor: 1169 Sq.Ft
  • Upper Floor (Sq.Ft.): N/A
  • Lower Floor (Sq.Ft.): N/A
  • Bonus Room (Sq.Ft.): N/A
  • Porch (Sq.Ft.): 52 Sq.Ft.
  • Garage (Sq.Ft.): N/A
  • Total Square Feet: 1247 Sq.Ft.
  • Customizable: Yes
  • Wall Construction: 2x4
  • Vaulted Ceiling Height: No
  • Main Ceiling Height: 8
  • Upper Ceiling Height: N/A
  • Lower Ceiling Height: N/A
  • Roof Type: Shingle
  • Main Roof Pitch: 6:12
  • Porch Roof Pitch: 6:12
  • Roof Framing Description: Stick
  • Designed Roof Load: 45lbs
  • Ridge Height (Ft.): 18
  • Ridge Height (In.): 4
  • Insulation Exterior: R13
  • Insulation Floor Minimum: R19
  • Insulation Ceiling Minimum: R30
  • Lower Bonus Space (Sq.Ft.): N/A
