House Plan 439 Hidden Hill Cove, Multi-Family House Plan

PDF: $1,550.00

Plan Details

  • Plan Number: NDG 439
  • Total Living Space:1697Sq.Ft.
  • Bedrooms: 3
  • Full Baths: 1
  • Half Baths: 1
  • Garage: Yes 2 Bay
  • Garage Type: Front Load
  • Carport: N/A
  • Carport Type: N/A
  • Stories: 1.5
  • Width Ft.: 105
  • Width In.: 8
  • Depth Ft.: 37
  • Depth In.: 10

Description

Family will thoroughly enjoy this duplex plan. The great room has a cozy fireplace and opens to the formal dining room and kitchen. A bay window sitting area has a wonderful view and access to the back yard. For privacy and convenience, the master suite is located on the main floor and has a large bathroom with whirlpool tub, separate shower, and large walk-in closet. Upstairs you'll find two additional bedrooms each with a large walk-in closet, private vanity and sharing a bathroom. A spacious bonus room has a dormer window seat and sloped ceiling. Floor Plan Specifications: Heat/Cooled Unit 1 & 2 Main Floor: 1048 SQ. FT Heat/Cooled Unit 1 & 2 Upper Floor: 649 SQ. FT Heat/Cooled Total: 3349 SQ. FT Garage, Storage, & Porch Unit 1 & 2: 521 SQ. FT Total: 4436 SQ. FT Bonus Room 1 & 2: 295 SQ. FT Total Bonus Room 1 & 2: 590 SQ. FT

Specifications

  • Total Living Space:1697Sq.Ft.
  • Main Floor: 1048 Sq.Ft
  • Upper Floor (Sq.Ft.): 649 Sq.Ft.
  • Lower Floor (Sq.Ft.): N/A
  • Bonus Room (Sq.Ft.): 295 Sq.Ft.
  • Porch (Sq.Ft.): 208 Sq.Ft.
  • Garage (Sq.Ft.): 834 Sq.Ft.
  • Total Square Feet: 2739 Sq.Ft.
  • Customizable: Yes
  • Wall Construction: 2x4
  • Vaulted Ceiling Height: No
  • Main Ceiling Height: 9
  • Upper Ceiling Height: 8
  • Lower Ceiling Height: N/A
  • Roof Type: Shingle
  • Main Roof Pitch: 12:12
  • Porch Roof Pitch: N/A
  • Roof Framing Description: Stick
  • Designed Roof Load: 45lbs
  • Ridge Height (Ft.): 25
  • Ridge Height (In.): 0
  • Insulation Exterior: R13
  • Insulation Floor Minimum: R19
  • Insulation Ceiling Minimum: R30
  • Lower Bonus Space (Sq.Ft.): N/A
