House Plan 279A Sage Meadows, Southern House Plan
Floor plans
NDG 279A
House Plan 279A Sage Meadows, Southern House Plan
PDF: $700.00
Plan Details
- Plan Number: NDG 279A
- Total Living Space:1359Sq.Ft.
- Bedrooms: 3
- Full Baths: 2
- Half Baths: N/A
- Garage: Yes 2 Bay
- Garage Type: Front Load
- Carport: No
- Carport Type: N/A
- Stories: 1
- Width Ft.: 46
- Width In.: N/A
- Depth Ft.: 60
- Depth In.: 5
Description
Throughout this home, you’ll feel the openness achieved by the grandeur of 9′ ceilings. A covered rear porch makes entertaining friends and family a breeze, and perfect for a delicious summer barbecue. Elegant french doors lead you back inside where you’ll enjoy conversation in your spacious great room, conveniently accessible to the dining area and kitchen. An additional third bedroom can be converted to a den or study to accommodate everyone.
Specifications
- Total Living Space:1359Sq.Ft.
- Main Floor: 1359 Sq.Ft
- Upper Floor (Sq.Ft.): N/A
- Lower Floor (Sq.Ft.): N/A
- Bonus Room (Sq.Ft.): N/A
- Porch (Sq.Ft.): 144 Sq.Ft.
- Garage (Sq.Ft.): 466 Sq.Ft.
- Total Square Feet: 1969 Sq.Ft.
- Customizable: Yes
- Wall Construction: 2x4
- Vaulted Ceiling Height: No
- Main Ceiling Height: 9
- Upper Ceiling Height: N/A
- Lower Ceiling Height: N/A
- Roof Type: Shingle
- Main Roof Pitch: 12:12
- Porch Roof Pitch: N/A
- Roof Framing Description: Stick
- Designed Roof Load: 45lbs
- Ridge Height (Ft.): 23
- Ridge Height (In.): 7
- Insulation Exterior: R13
- Insulation Floor Minimum: R19
- Insulation Ceiling Minimum: R30
- Lower Bonus Space (Sq.Ft.): N/A
