House Plan 5082 French Manor, European House Plan

House Plan MEN 5082 Main Floor
House Plan MEN 5082 Upper Floor
House Plan MEN 5082 Main Floor
House Plan MEN 5082 Upper Floor

Floor plans

House Plan MEN 5082 Main Floor

House Plan MEN 5082 Upper Floor
MEN 5082

House Plan 5082 French Manor, European House Plan

PDF: $2,250.00

Plan Details

  • Plan Number: MEN 5082
  • Total Living Space:5106Sq.Ft.
  • Bedrooms: 6
  • Full Baths: 6
  • Half Baths: 1
  • Garage: 5 Bay Yes
  • Garage Type: Side Load
  • Carport: N/A
  • Carport Type: N/A
  • Stories: 1.5
  • Width Ft.: 122
  • Width In.: 4
  • Depth Ft.: 82
  • Depth In.: 2

Description

There is plenty of space for the whole family in this luxury french country house plan. The open floor plan design creates the perfect gathering area for friends and family where conversation and laughter can flow uninterrupted from the kitchen and breakfast room into the great room all of which is accented by beautiful 10' ceilings and foe timber beams. On either side of the foyer you'll find duel purpose rooms that can be used whichever way will best fit your family. On the left is the formal dining room that can be used as a study if formal dining is not your style. On the right is the beautiful office or study with the large rounded wall covered in windows. Three large rooms are located behind the great room each boasting an en-suit bathroom and walk-in closet. Tucked away on the other side of the home is the spacious master suite with a huge walk-in closet and direct access to the outdoor living porch. Upstairs you'll find a game room and guest room allowing your visitors their own private space. Attached to the home but separated by one of the garages is the in-laws suite complete with a kitchen, den, spacious bedroom and bathroom with a stacked washer and dyer.

Specifications

  • Total Living Space:5106Sq.Ft.
  • Main Floor: 4492 Sq.Ft
  • Upper Floor (Sq.Ft.): 614 Sq.Ft.
  • Lower Floor (Sq.Ft.): N/A
  • Basement (Sq.Ft.): N/A
  • Bonus Room (Sq.Ft.): N/A
  • Porch (Sq.Ft.): 505 Sq.Ft.
  • Garage (Sq.Ft.): 1873 Sq.Ft.
  • Total Square Feet: 7484 Sq.Ft.
  • Customizable: Yes
  • Wall Construction: 2x6
  • Vaulted Ceiling Height: No
  • Main Ceiling Height: 9
  • Upper Ceiling Height: 9
  • Lower Ceiling Height: N/A
  • Roof Type: Shingle
  • Main Roof Pitch: 12:12
  • Porch Roof Pitch: N/A
  • Roof Framing Description: Stick
  • Designed Roof Load: 45lbs
  • Ridge Height (Ft.): 39
  • Ridge Height (In.): 6
  • Insulation Exterior: R13
  • Insulation Floor Minimum: R19
  • Insulation Ceiling Minimum: R30
  • Lower Bonus Space (Sq.Ft.): N/A
